ETFE Powder
ETFE Powder
Product Description
Ethylene-tetragas ethylene copolymer, or ETFE for short, is one of the strongest fluoroplastics with good mechanical properties, weather resistance, flame retardancy, gas barrier and chemical resistance. In addition to the excellent properties of other fluororesins, it also has the characteristics of radiation resistance, strong adhesion to metal surfaces, and lighter than other gas materials. ETFE products are divided into three forms: powder, liquid and granule, which can be widely used in chemical, agricultural, construction, electronics, automotive and other fields through spraying, roller extrusion, injection molding and other processing technologies to anti-corrosion lining, film, hose, cable and other molded parts.
Grades of ETFE Powder
|
function |
Grille |
Cliunclciislic |
|
Thin Coating |
ET620B |
White powder,suitable for 100～500μm solid color coating |
|
ET620BBK |
Black powder,suitable for 100～500μm black coating |
|
|
IT6203WT |
White powder,suitable for 100~500μm white coating |
|
|
ET620BGNI |
Green powder,suitable for 100～500μm dark green coating |
|
|
ET620BGN2 |
Green powder,suitable for 100～500μm bright green coating |
|
|
thick Coating |
ET620H |
White powder,suitable for 500～1000μm solid color coating |
|
ET620HfBK |
Black powder,suitable for 500～1000μm black coating |
|
|
ET620HWT |
While powder,suitable for 500～1000μm white coating |
|
|
ET6201GNI |
Green powder,suitable for 500～1000μm dark green coating |
|
|
ET6201GN2 |
Green powder,suitable for 500~1000μm bright green coating |
|
|
Anti static coatings |
ET620AS |
Black powder,suitable for 100-1000μm black,anti static coating |
|
Rotational rotational molding |
E1630R |
While powder.rotary rolling,suitable for 2000~8000μm pure color coating |
Propertics of ETFE Powder
|
Ptopenty |
Lm |
Mefliod |
Sunce Qonting Sers |
Routing Rotormlding |
|
Appearance Density |
g/ml |
--- |
≥0.60 |
≥0.70 |
|
Average Particle Size |
μm |
Laser Particle Size Analyzer |
40 ~ 90 |
200 ~ 500 |
|
Melting Point |
℃ |
DSC |
220 ~ 230 |
220 ~ 230 |
|
MFR |
g/10min |
ASTM-D3159(297℃*49N) |
15 ~ 20 |
20 ~ 30 |
|
Tensile Strength |
MPa |
HG/T2904-1997 |
≥30 |
≥30 |
|
Elongation |
% |
HG/T2904-1997 |
≥300 |
≥300 |
|
Surface Resistance |
Ω |
Surface Resistance Detector |
10⁴-1010(Antistatic Coating) |
--- |
Packaging
ETFE powder products, double-layer polyethylene packaging sealed and packed, 10KG/bag, 20KG/carton
NOTES
1. When the product is applied and processed, the corresponding labor protection equipment should be worn to eliminate potential safety hazards such as dust and toxic gas inhalation, high temperature burns, etc., open flames and smoking are strictly prohibited in the workplace, and the corresponding exhaust device should be installed;
2. Products that have not been put into use after opening must be strictly sealed to prevent foreign substances from being mixed;
3. The product is stored in a cool and ventilated place, away from fire and heat sources;
4. Pay attention to sunscreen, moisture-proof, vertical and light during transportation;
5. Product waste must be disposed of in accordance with relevant laws and regulations.
|
|
|
|
|
|
|
